Why choose dock shelters from Hörmann?
Reliable solutions, all manufactured in-house
- Large selection of flap, cushion and inflatable shelters for all loading situations
- Modern, in-house production with a high level of vertical integration
- Solutions for all fitting situations: For new buildings and renovations, at the hall or in loading tunnels
- Tried and tested safety, compliant with standards
- Long service life, even with intensive use
- Easy fitting and maintenance-friendly construction
Advantages of dock shelters
Long-lasting sealing, effective protection
- Safety: Protection against weather effects, draughts and dust for goods and people
- Energy efficiency: Reduction in heating and cooling costs
- Efficiency: Optimum goods handling thanks to efficient logistics processes
- Quality assurance: Temperature control and maintenance of the cold chain
Overview of dock shelters
Ideal solutions for every location
Hörmann offers a wide range of options, including flap, inflatable and cushion dock shelters: There are different models in each category, so you can find the ideal solution for all loading situations. All dock shelters are manufactured in-house. This ensures reliable quality and durability, enabling us to offer you special solutions.
Flap dock shelter
Hörmann flap dock shelter consist of robust top and side flaps that are mounted on a galvanised, compressible frame. They are flexible yet stable, and can adapt to vehicles of different sizes. This makes them ideal for loading sites where lorries of various heights and widths are loaded and unloaded. Hörmann flap dock shelter are particularly durable and are the most commonly used type of dock shelter.
- Flexible frame connection as a link arm or scissors arm
- Optional: top flap with side cut, edge or full section
- Optional: electric rolling flap for sealing smaller docking vehicles
- Long-lasting and durable
- Optional corner cushions for even better sealing between wall connection and flap
Inflatable dock shelters
Inflatable dock shelters are the ideal solution when a tight seal is required for a door opening. This makes them ideal for cold stores and temperature-controlled storage areas. The lorry docks without the air cushions coming into contact with the vehicle. Instead, they are filled by a fan afterwards. This increases their service life, and the door seal automatically adapts to different vehicle dimensions. Inflatable dock shelters are particularly well suited for use in DOBO systems (docking before opening) because they do not prevent vehicle doors from being opened after docking.
- Frame construction made of insulated steel panels
- Excellent sealing
- Ideal for DOBO systems
- Optionally available with electrical roll-up flap instead of top cushion for greater flexibility
- Available as a dock or roadway model, in recess version or for loading houses
Cushion dock seals
Cushion dock seals are an excellent choice when vehicles with very similar dimensions dock at the loading site. They can be tailor-made to suit the vehicle fleet in use. The Hörmann BBS2 cushion dock seal is ideal for docking different types of delivery vans: thanks to flexible side cushions and an adjustable top cushion, it adapts effortlessly to all common vehicle heights and contours.
The following applies to all cushion dock seals: they create a very tight seal, closing not only the gap between the rear of the lorry and the building, but also the air gap between the lorry and the open doors. The cushions are filled with PU foam. Together with the sturdy base frame and a casing made of fabric-reinforced plastic flaps, they form a durable unit.
- Particularly good sealing
- Also suitable for cold stores and air-conditioned storage areas
- With fixed side and top cushions and optional additional top flap or – particularly adaptable – with flexible side cushions and adjustable top cushion (BBS2)
Solutions for special requirements
Perfectly matched to your application area
- Solutions for maximum flexibility: The no-linkage flap dock shelter DDF 10 is particularly robust and flexible for use with different vehicle sizes. Its foam-filled side cushions are compressed or deflected to the side in the event of inaccurate docking. The movable top part can move upwards when a docked vehicle is pumped up.
- Solutions for hanging goods: The dock seal DAK 3 is ideal for goods transported in a hanging position. It features fixed side cushions and an inflatable top cushion. This leaves the loading opening at the top free, allowing goods to be transferred directly onto conveyor systems.
- Solutions for parcel services and small vans: The cushion dock seal BBS2 from Hörmann is ideal for parcel services and small vans. Thanks to its flexible, foam-filled side cushions and adjustable top cushion, it adapts perfectly to the contours of the vehicle – from the Mercedes Sprinter H1/2/3/4 and Iveco Daily to VW vans.
- Inexpensive solutions: The inexpensive flap dock shelters DSL Basic and DSLR Basic offer proven Hörmann quality with a sturdy link arm construction, two-layered backing fabric, and monofilament reinforcement. They are available exclusively in the dimensions 3300 × 3500 × 600 mm (W × H × D).
For more information, see our brochure!
Equipment and safety systems for loading technology from Hörmann
Many components help to create a safe and convenient loading site. We also offer a wide range of tried-and-tested accessories to meet all requirements.
Fitting and maintenance
Hörmann dock shelters are designed for quick and straightforward installation, requiring only a limited number of fixing points. Clear, easy-to-follow instructions also simplify ongoing maintenance, helping to minimise downtime and ensure long-term performance.
To support your operation throughout the product lifecycle, Hörmann provides expert technical advice, maintenance and repair services, along with a guaranteed spare parts availability period of up to 10 years for dock shelters.
Our tip for ensuring the dock seals have a particularly long service life:
- Ensure accurate vehicle positioning – careful, centred docking helps reduce wear and damage. Wheel guides can provide valuable assistance and improve docking accuracy.
- Choose the right dock seal for the application – inflatable dock seals, such as the DAS3, only make contact with the vehicle after docking, significantly reducing wear. The DDF10 dock shelter is also designed to minimise the risk of accidental damage.
- Maintain regular cleaning routines – Keeping curtains and sealing elements clean helps maintain performance and can extend the service life of the dock shelter.
Contact us today
Planning a loading site requires considerable expertise and experience. We are happy to support you throughout this process, ensuring that your system is perfectly tailored to your requirements and meets all relevant safety and quality standards.
